Source
• Light source type: 40W RGBW multichips
• LED life expectancy: min. 20.000 hours
• Typical lumen maintenance: 70% @ 20.000 hours
Système optique
• 200mm parabolic aluminium reflector with special gold-brown coating
• half-ball diffusor dome distributing light evenly from RGBW LED source inside of the reflector
Effets et fonctions dynamiques
• Colour mixing mode RGBW or CMY
• Variable CTO: 2.700K – 8.000K
• Virtual Colour Wheel: with 66 preset swatches
• Pre-programmed pixel effects with colour, dimming and strobe chases, waves and pulses at variable speed and
direction
• Shutter: Electronic with variable speed strobe (max. 20 flashes per second)
• Pre-programmed random strobe & pulse effects
• High resolution electronic dimming: 0 – 100%
Contrôle et programmation
• PATT Driver: external
• Setting & Addressing: two-row LCD display & 4 control buttons
• Protocols: USITT DMX-512, RDM, ArtNet, Kling-Net, sACN
• Wireless CRMX™ technology from Lumen Radio: On request
• DMX Protocol modes: 6
• Control channels: 13, 32, 40, 47, 53, 60
• RGBW or CMY: 8 or 16 bit (internal 18 bit)
• Dimmer: 8 or 16 bit (internal 18 bit)
